C H A M P I O N

S  E  T  U  P      T  I  P  S


*Note: Prop size (pitch) will vary with Altitude, Water Temperature, Humidity and loaded conditions of the boat. The recommendations below are based on a 2 person tournament load.  Motors mounted on jackplates in 3rd hole and centered in slots.  Move up and down for optimum performance.


MERCURY PROP CHART

Model HP 200 200 Opti 225 225 Opti 250 300
223 Prop 23 Tempest 24 Trophy 25 Trophy 25 Trophy 25 Trophy 25 Trophy
  Hole 3rd 3rd 3rd 3rd 3rd 3rd
221 Prop 23 Tempest 24 Trophy 25 Trophy  25 Trophy 25 Trophy  25 Trophy
  Hole 3rd 3rd 3rd 3rd 3rd 3rd
206 Prop 25 Tempest 24 Trophy 25 Trophy 25 Trophy 25 Trophy 25 Trophy
DC, SC Hole 3rd 3rd 3rd 3rd 3rd 3rd
203 Prop 25 Tempest 24 Trophy 25 Trophy 25 Trophy 25 Trophy 25 Trophy
DC, SC Hole 3rd  3rd 3rd 3rd 3rd 3rd
202 Prop 25 Tempest 24 Trophy 25 Trophy 25 Trophy 25 Trophy 25 Trophy
DC, SC, F/S Hole 3rd 3rd 3rd 3rd 3rd 3rd
Model HP 150 175 200 200 Opti 225 225 Opti
196 Prop 23 Trophy 23 Trophy 23 Trophy 23 Trophy 25 Trophy 25 Trophy
DC, SC Hole 2nd 2nd 2nd 2nd 3rd 3rd
194 Prop 23 Tempest 23 Tempest 25 Tempest 25 Trophy
FH Hole 3rd 3rd 3rd 3rd
193 Prop 23 Tempest 23 Tempest 25 Tempest 25 Trophy
DC, SC Hole 3rd 3rd 3rd 3rd
191 Prop 23 Tempest 23 Tempest 25 Tempest 25 Tempest
DC, SC Hole 2nd 2nd 3rd 3rd
190 Prop 23 Tempest 23 Tempest 24 Trophy 24 Trophy
SX Hole 2nd 2nd 3rd 3rd
Model HP 135 150 175
187 Prop 23 Trophy 23 Tempest 25 Tempest
DC, SC Hole 3rd 3rd 3rd
186 Prop 23 Trophy 23 Tempest 25 Tempest
DC,SC,F/C Hole 2nd 2nd 3rd
Model HP 115 125 135 150 175
181 Prop 24 Trophy 24 Trophy 25 Trophy 23 Tempest 25 Tempest
DC,SC Hole 2nd 3rd 3rd 3rd 3rd
181 Prop 23 Trophy 24 Trophy 24 Trophy 23 Tempest
SX Hole 2nd 3rd 3rd 3rd
Model HP 75 90 100 115 125 135 150
171 Prop 23 Trophy 23 Trophy 23 Trophy 24 Trophy 24 Trophy 25 Trophy 25 Trophy
DC, SC Hole 2nd 2nd 2nd 2nd 3rd 3rd 3rd
Mean Prop 23 Trophy 24 Trophy 24 Trophy 25 Trophy
16 Hole 2nd 3rd 3rd 3rd

OMC PROP CHART

Model HP 150 175 200 225
223 Prop 23 Renegade 22 Raker 24 Raker 24 Raker
  Hole 3rd 3rd 3rd 3rd
203 Prop 22 Raker 24 Raker 24 Raker 25 Renegade
DC, SC Hole 3rd  3rd 3rd 3rd
202 Prop 22 Raker 24 Raker 24 Raker 25 Renegade
DC, SC, F/S Hole 2nd 2nd 2nd 2nd
194 Prop 22 Raker 22 Raker 24 Raker 24 Raker
FH Hole 2nd 2nd 2nd 3rd
191 Prop 23 Renegade 24 Raker 24 Raker
DC, SC Hole 2nd 2nd 3rd
190 Prop 22 Raker 22 Raker 24 Raker
SX Hole 2nd 2nd 3rd
Model HP 115 125 130 150 175
187 Prop     22 Raker 22 Raker 24 Raker
DC, SC Hole     3rd 3rd 3rd
186 Prop     22 Raker 22 Raker 24 Raker
DC,SC,F/C Hole     2nd 2nd 3rd
181 Prop 23 Raker 24 Raker 24 Raker 24 Raker 24 Raker
DC, SC Hole 2nd 3rd 3rd 3rd 3rd
181  Prop 23 Renegade 23 Renegade 24 Raker 24 Raker
SX Hole 2nd 2nd 3rd 3rd
171 Prop 22 Raker 24 Raker 24 Raker 24 Raker
DC, SC Hole 2nd 3rd 3rd 3rd
Model HP 90
Mean Prop 22 Raker
16 Hole 2nd

YAMAHA PROP CHART

Model HP 150 175 200 3.1 L 200 2.6L 225 3.1L
223 Prop     23 Pro 23 Pro 25 HD Pro
  Hole     3rd 3rd 3rd
221 Prop     23 Pro 23 Pro 25 HD Pro
  Hole     3rd 2nd 3rd
206 Prop     25 HD Pro 23 Pro 25 HD Pro
DC, SC Hole     3rd 3rd 3rd
203 Prop     25HD Pro 23 Pro 25 HDPro
DC, SC Hole     3rd 3rd 3rd
202 Prop     25HD Pro 23 Pro 25 HD Pro
DC, SC, F/S Hole     2nd 2nd 3rd
196 Prop 23 Pro 23 Pro 25 HD Pro 23 Pro
DC, SC Hole 3rd 3rd 3rd 3rd
194 Prop 23 Pro 23 Pro 25 HD Pro 25 HD Pro 25 HD Pro
FH Hole 2nd 2nd 2nd  3rd 3rd
193 Prop 23 Pro 23 Pro 25 HD Pro 23 Pro
DC, SC Hole 3rd 3rd 3rd 3rd
191 Prop 23 Pro 23 Pro 25 HD Pro 23 Pro
DC, SC Hole 2nd 2nd 3rd 2nd
190 Prop 23 Pro 23 Pro 25 HD Pro 23 Pro
SX Hole 2nd 2nd 3rd 2nd
187 Prop 23 Pro 25 HD Pro
DC, SC Hole 2nd 3rd
186 Prop 23 Pro 25 HD Pro
DC,SC, F/C Hole 2nd 3rd
Model HP 115 F115 130 150 175
181 Prop 18GYT3GYT4 18GYT3GYT4 20GYT3GYT4 23 Pro 25 HD Pro
DC, SC Hole 3rd 3rd 3rd 3rd 3rd
181  Prop 18GYT3GYT4 18GYT3GYT4 20GYT3GYT4 23 Pro
SX Hole 3rd 3rd 3rd 3rd
171 Prop   20 GYT3GYT4 20GYT3GYT4 25 HD Pro
DC, SC Hole   3rd 3rd 3rd
Model HP 70 90 F100 115 F115
Mean Prop 18 SST 18GYT3GYT4 20GYT3GYT4 20GYT3GYT4 20GYT3GYT4
16 Hole 2nd 3rd 3rd 3rd 3rd
